What is Zanzibar?

Zanzibar is Google’s global authorization system designed to store and evaluate access control lists (ACLs) for a wide range of services, including Calendar, Cloud, Drive, Maps, Photos, and YouTube. It offers a uniform data model and configuration language to express diverse access control policies.

Key Features of Zanzibar

• Correctness: Ensures consistent access control decisions.

• Flexibility: Supports a rich set of access control policies.

• Low Latency: Responds quickly to authorization checks.

• High Availability: Reliably handles requests.

• Large Scale: Manages trillions of ACLs and millions of requests per second.

Data Model and Configuration

Defining the Tuple Data Model

Zanzibar uses relation tuples to represent ACLs. These tuples can include groups and nested group memberships. The tuple format is as follows:

⟨tuple⟩ ::= ⟨object⟩‘#’⟨relation⟩‘@’⟨user⟩
⟨object⟩ ::= ⟨namespace⟩‘:’⟨object id⟩
⟨user⟩ ::= ⟨user id⟩ | ⟨userset⟩
⟨userset⟩ ::= ⟨object⟩‘#’⟨relation⟩

Example Tuples:

doc:readme#owner@10          # User 10 is an owner of doc:readme

group:eng#member@11         # User 11 is a member of group:eng

doc:readme#viewer@group:eng#member  # Members of group:eng are viewers of doc:readme

Namespace Configuration

Before clients can store relation tuples in Zanzibar, they must configure their namespaces. A namespace configuration specifies its relations as well as its storage parameters. Each relation has a name and a relation config. Storage parameters include sharding settings and an encoding for object IDs.

Userset Rewrite Rules

Userset rewrite rules allow clients to define relationships between different relations in a namespace. These rules enable the creation of complex access control policies by specifying how one relation can be derived from another. In the given example, the namespace is "doc", and it defines three relations: "owner", "editor", and "viewer".

Configuration Breakdown

name: "doc"
relation { name: "owner" }
relation {
    name: "editor"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "owner" } }
        }
    }
}
relation {
    name: "viewer"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "editor" } }
        }
    }
}

Relations Defined

1. owner: This is a basic relation that directly specifies the owners of a document.

2. editor: This relation is defined with a userset rewrite rule that combines the current editors (_this) with the owners (computed_userset { relation: "owner" }).

3. viewer: This relation is defined with a userset rewrite rule that combines the current viewers (_this) with the editors (computed_userset { relation: "editor" }).

Userset Rewrite Rules

editor Relation

relation {
    name: "editor"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "owner" } }
        }
    }
}

• _this: Refers to the current set of users who have the editor relation.

• computed_userset { relation: "owner" }: Computes the set of users who have the owner relation.

The union operation combines these two sets, meaning that anyone who is an owner of a document is also considered an editor.

viewer Relation

relation {
    name: "viewer"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "editor" } }
        }
    }
}

• _this: Refers to the current set of users who have the viewer relation.

• computed_userset { relation: "editor" }: Computes the set of users who have the editor relation.

The union operation combines these two sets, meaning that anyone who is an editor of a document is also considered a viewer.

Practical Example

Let’s say we have the following relation tuples:

doc:example#owner@alice       # Alice is the owner of the example document
doc:example#editor@bob        # Bob is an editor of the example document
doc:example#viewer@charlie    # Charlie is a viewer of the example document

Based on the userset rewrite rules:

• Editors: The set of editors includes both bob (explicitly defined) and alice (implicitly included because she is an owner).

• Viewers: The set of viewers includes charlie (explicitly defined), bob (implicitly included because he is an editor), and alice (implicitly included because she is an owner).

Enjoying What You Read?

Subscribe to our newsletter for more insightful content like this!

Subscribe Now

Check Evaluation

Zanzibar evaluates ACL checks by converting check requests to boolean expressions. For example:

CHECK(U, ⟨object#relation⟩) =
			∃ tuple ⟨object#relation@U⟩
			∨ ∃ tuple ⟨object#relation@U′⟩, where
					U′ = ⟨object′#relation′⟩ s.t. CHECK(U,U′).

Example Scenario

Consider a document named example with the following relation tuples:

doc:example#owner@alice       # Alice is the owner of the example document
doc:example#editor@bob        # Bob is an editor of the example document
doc:example#viewer@charlie    # Charlie is a viewer of the example document

And the namespace configuration for doc is:

name: "doc"
relation { name: "owner" }
relation {
    name: "editor"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "owner" } }
        }
    }
}
relation {
    name: "viewer"
    userset_rewrite {
        union {
            child { _this {} }
            child { computed_userset { relation: "editor" } }
        }
    }
}

Check Evaluation: Does david have viewer access to doc:example?

To evaluate this, Zanzibar will follow these steps:

1. Direct Check: First, Zanzibar checks if david is directly listed as a viewer of doc:example.

   • There is no direct tuple for david as a viewer.

2. Inherited Check: Next, Zanzibar checks if david is an editor of doc:example because viewers include editors.

   • There is no direct tuple for david as an editor.

3. Further Inherited Check: Finally, Zanzibar checks if david is an owner of doc:example because editors include owners.

   • There is no direct tuple for david as an owner.

Since david is not directly or indirectly listed as a viewer, editor, or owner of doc:example, the check evaluation concludes that david does not have viewer access to doc:example.

Check Evaluation: Does bob have viewer access to doc:example?

To evaluate this, Zanzibar will follow these steps:

1. Direct Check: First, Zanzibar checks if bob is directly listed as a viewer of doc:example.

   • There is no direct tuple for bob as a viewer.

2. Inherited Check: Next, Zanzibar checks if bob is an editor of doc:example because viewers include editors.

   • There is a direct tuple for bob as an editor.

Since bob is an editor of doc:example, and viewers include editors, the check evaluation concludes that bob has viewer access to doc:example.

Check Evaluation: Does alice have viewer access to doc:example?

To evaluate this, Zanzibar will follow these steps:

1. Direct Check: First, Zanzibar checks if alice is directly listed as a viewer of doc:example.

   • There is no direct tuple for alice as a viewer.

2. Inherited Check: Next, Zanzibar checks if alice is an editor of doc:example because viewers include editors.

   • There is no direct tuple for alice as an editor.

3. Further Inherited Check: Finally, Zanzibar checks if alice is an owner of doc:example because editors include owners.

   • There is a direct tuple for alice as an owner.

Since alice is an owner of doc:example, and editors include owners, and viewers include editors, the check evaluation concludes that alice has viewer access to doc:example.

Summary

Zanzibar’s check evaluation process involves:

1. Checking for direct relations.

2. Checking for inherited relations based on userset rewrite rules.

3. Combining these checks to determine if a user has the requested relation to an object.

This approach allows Zanzibar to handle complex access control policies efficiently and consistently.

API

Zanzibar provides several APIs:

• Check: Determines if a user has a specific relation to an object.

• Read: Retrieves relation tuples.

• Write: Modifies relation tuples.

• Watch: Monitors changes to relation tuples.

• Expand: Returns the effective userset for an object-relation pair.

Architecture

Zanzibar’s architecture includes:

• aclservers: Handle Check, Read, Expand, and Write requests.

• watchservers: Respond to Watch requests.

• Spanner: A globally distributed database system that stores ACLs and metadata.

• Leopard: An indexing system for efficient set computations.

Performance Optimizations

Distributed Caching

Zanzibar employs a distributed cache to store results of recent checks and reads. This helps in handling hot spots and reducing latency. Cache entries are distributed across Zanzibar servers using consistent hashing.

Request Hedging

To mitigate tail latency, Zanzibar uses request hedging. This involves sending the same request to multiple servers and using the first response that arrives. This technique helps in accommodating slow tasks without significantly increasing load.

Performance Isolation

Zanzibar implements performance isolation to ensure that misbehaving clients or unexpected usage patterns do not affect other clients. This is achieved through:

• CPU Capacity Allocation: Each client has a global limit on maximum CPU usage per second.

• Memory Usage Limits: Each server limits the total number of outstanding RPCs to control memory usage.

• Spanner Server Limits: Limits the maximum number of concurrent reads per (object, client) and per client on each Spanner server.

Real-Life Example

Imagine a photo-sharing service where users can share photos with specific groups. Using Zanzibar, the service can efficiently manage ACLs to ensure that only authorized users can view or edit photos. For example:

photo:vacation#owner@alice       # Alice is the owner of the vacation photo
group:family#member@bob          # Bob is a member of the family group
photo:vacation#viewer@group:family#member  # Family members can view the vacation photo

Code Sample

Here’s a simplified example of how you might use Zanzibar’s API to check if a user has permission to view a photo:

from zanzibar_client import ZanzibarClient

client = ZanzibarClient()

# Check if Bob can view the vacation photo
result = client.check("photo:vacation", "viewer", "bob")
print("Bob can view the photo:", result)

Graphs and Data

Deep Dive into Zanzibar’s Components

Aclservers

Aclservers are the primary servers in Zanzibar’s architecture. They handle various types of requests:

• Check Requests: Determine if a user has a specific relation to an object.

• Read Requests: Retrieve relation tuples.

• Expand Requests: Return the effective userset for an object-relation pair.

• Write Requests: Modify relation tuples.

Watchservers

Watchservers are specialized servers that respond to Watch requests. They tail the changelog and serve a stream of namespace changes to clients in near real-time.

Spanner

Spanner is a globally distributed database system used by Zanzibar to store ACLs and their metadata. It provides external consistency and snapshot reads with bounded staleness, ensuring that ACL evaluations respect the causal ordering of updates.

Leopard

Leopard is an indexing system used to optimize operations on large and deeply nested sets. It reads periodic snapshots of ACL data and watches for changes between snapshots. Leopard performs transformations on the data, such as denormalization, and responds to requests from aclservers.

Learnings from Zanzibar’s System Design

1. Unified Data Model: Zanzibar’s use of a unified data model for ACLs and groups simplifies the representation and management of access control policies.

2. External Consistency: By leveraging Spanner’s TrueTime mechanism, Zanzibar ensures that ACL evaluations respect the causal ordering of updates, preventing issues like the “new enemy” problem.

3. Scalability: Zanzibar’s architecture, with its distributed servers and caching mechanisms, allows it to scale to trillions of ACLs and millions of requests per second.

4. Low Latency: Techniques like distributed caching, request hedging, and performance isolation help Zanzibar achieve low latency, even under high load.

5. Flexibility: The system’s configuration language and userset rewrite rules provide the flexibility needed to accommodate a wide range of access control policies.

Conclusion

Zanzibar is a powerful authorization system that ensures consistent, scalable, and performant access control across Google’s services. By understanding its data model, consistency model, and architecture, developers can build robust authorization mechanisms in their own applications. Whether you’re a college student learning about system design or a senior engineer looking to implement a global authorization system, Zanzibar offers valuable insights and techniques.

---

Have you worked with authorization systems before? How do you ensure consistency and scalability in your projects? Share your experiences and thoughts in the comments below!

---

References

1. Pang, R., Cáceres, R., Burrows, M., et al. (2019). Zanzibar: Google’s Consistent, Global Authorization System. USENIX Annual Technical Conference (USENIX ATC ’19).

2. Google Cloud Identity and Access Management. https://cloud.google.com/iam/
